SF-200 Digital Signage Device
A Digital Signage Device that is Simple. Reliable. Affordable.
The SF-200 digital signage device is powerful, bringing speed and an expanded feature set to a wide range of industries and applications including Andon Boards, Corporate Communications Displays, Digital Menu Boards, and Digital Reader Boards. If professional, enterprise-level features are needed, along with the simplicity of an entry level solution, the SF-200 digital signage device is the right choice!
Specifications
| Model Number | SF-200 |
| Size | L: 5.1″ (129.5mm) – W: 3.9″ (99.1mm) – H: 1.5″ (38.1mm) |
| Weight | 6 Ounces (170 Grams) |
| Resolutions | 640X480, 1024X768, 1280X1024, 1600X1200, 800X600, 1280X720, 1366X768, 1920X1080 |
| Output | HDMI (VGA & DVI Adapters Available) |
| Power | US, EU & UK (Adapters Sold Separately) |
| Connectivity | Power, SD Card*, USB (x2), RS-232, WIFI*, Ethernet, HDMI Out, Composite & Component Video*, Digital Audio**Feature coming soon |
| Environment | Ambient from -40°F to 145°F (-40°C TO 63° C) Altitude: 16,000´ Humidity: 0-80% (Non-condensating) |
| Power Supply | Input: 100-240V – 50/60HZ 0.5A Output: 12V 1.5A |
| Video Formats | Bluray Quality HD MPEG4 & WMV |
| Graphic Formats | PNG, JPG, GIF, BMP, TIF |
| Certifications | CE Approval, ROHS |
You can download a PDF of these specs in the Downloads Section
- Reliable — Our little green box is not a PC and has no moving parts, which means there is nothing to break, and nothing to crash
- Mount It Anywhere — Its small size enables the SF-200 digital signage device to be installed behind each screen, or even in the wall if needed – No ventilation is needed
- USA ‘Born and Bred’ — To our knowledge, the SF-200 digital signage device is the only USA designed and assembled digital signage device, which means unprecedented support and rock solid USA quality
- Durable — Endures extreme temperatures, so it is right at home in any environment
- Video Playback — Bluray quality full-screen video playback can be looped, scheduled and as many videos as you like can be added to the sequence!
- Enterprise Level Software — The SF-200 digital signage device works exclusively with the Noventri Suite and Noventri Server.
- Eco-Friendly — Eliminates waste of paper signs, controls the screen through RS-232 to reserve energy, and the hardware was designed to be so efficient that it consumes less power every year than the cost of a cup of coffee
- Easy Setup — Nothing complex here…just set it and forget it!
- Field Updatable — Firmware updates come to the player automatically, which makes keeping the SF-200 up-to-date hassle free. The revolutionary hardware is updated and changed without laying a finger on the box
Additional Resources
Warranty
Accessories
IR Remote Control
 |
Configure and reboot the SF-200 from a distance |
Universal Mounting Plate
 |
Mount the SF-200 with ease by using this mounting plate. Comes with holes pre-drilled with standard hole-patterns found on most commercial grade LCD displays. |
USB-RS232 Cable
 |
Designed for the best and most reliable control over your RS-232 devices. |
Ships With
 |
SF-200 |
 |
Commercial Grade 8GB USB Drive |
 |
Quick Start Guide |
 |
Enterprise grade power supply |
